5-Gallon Universal Aluminum Fuel Tank, 12" x 12" x 8" (#11006)

A simple, unbaffled 5-gallon universal tank built from 1/8" 5052 aluminum, with one installed pickup tube and two 3/8" NPT top ports for a vent and a return. You choose the fill cap or neck, an optional sender flange and extra pickup tubes at checkout.

Technical Specifications

Product number: 11006
Capacity: 5 gallons
Body dimensions: 12" L x 12" W x 8" H
Footprint: 15" x 12" including mounting tabs
Height with cap: 10.5" max
Material and thickness: 5052 aluminum, 0.125" (1/8"), mill finish
Baffles: None
Weld fittings: 6061-T6 aluminum, flush style
Fill: 2" NPSM or 225 Series neck, or 2.0" / 1.5" OD hose barb
Vent: 3/8" NPT
Sender provision: Optional 5-bolt SAE flange
Pickup / draw: 3/8" NPT
Return: 3/8" NPT
Drain: None
Mounting: Four 1.5" 5052 aluminum slotted mount tabs; slot centers 13.62" x 8.00"; 15" overall length including tabs
Dry weight: 10 lb (approx.)
Pressure test: Fully pressure tested (5–8 psi) and inspected
Fuel: Gasoline or diesel. Choose a cap rated for your fuel.
Warranty: 2-year limited structural warranty
Custom / modified tanks: 5–10 piece order required (no single-tank changes)
Bulk pricing: available from 10 pieces

Tank Options & Provisions

Fill (Tank Cap / Neck Option)
On top. There is no standard neck; the fill is set by the cap or neck you choose at checkout. Choose one rated for your fuel. All tanks must be vented to work properly. With a non-vented cap, vent the tank through a 3/8" NPT port or use a managed vent cap. Open vented caps will leak.

Vent
3/8" NPT flush 6061-T6 aluminum port on top. Plumb it to a vapor canister or filter.

Sending Unit (Flange & Level Sensor Option)
The tank does not come with a level sensor mount. Add a 5-bolt SAE sender flange at checkout and install your own sensor, or have us install the flange with a block-off kit or a mechanical gauge. A sensor or block-off must be installed on the flange before the tank is used.

No Thanks
Add Sensor Flange Only
Add Flange W/ Blockoff Kit Installed
Add Flange W/ Mechanical Gauge Installed

Pickup (Pickup Tube Options)
One pickup tube is installed: 3/8" NPT half coupling on top, 1/4" Sch 40 aluminum tube, 7.75" long with a 15° cut. One is all you need unless you're running multiple engines.

No Thanks- 1 pickup tube is all I need.
Install (1) Additional Pickup Tube (2 Pickups Total)
Install (2) Additional Pickup Tubes (3 Pickups Total)
Install (3) Additional Pickup Tubes (4 Pickups Total)

Return
3/8" NPT flush 6061-T6 aluminum port on top.

Drain
This tank has no drain port.

Included

Tank with one pickup tube installed
Fill cap or neck, sender flange option and extra pickup tubes as selected at checkout

Not Included

Final threaded fittings, plugs and mounting hardware for your install (we do not sell these)

Install Notes

The tank must be vented. Open vented caps will leak. Plumb the 3/8" NPT vent port to a vapor canister or filter, or use a managed vent cap.
If you add the sender flange, a sensor or block-off kit must be installed on it before the tank is used.
Aluminum threads cross-thread and gall easily. Start every plug and fitting by hand and never install them dry. Thread damage from dry-fitted plugs or hardware isn't covered under warranty.
Measure your application before ordering. Full dimensions and port locations are on the reference drawing in the product photos.
Put rubber isolator pads (or similar rubber isolation) under the mounting tabs to isolate the tank from vibration and chafe.
See our Universal Fuel Tank Selection, Install & Fitment Guide to compare sizes, ports, venting, mounting and level sensors.

FAQ

What size fittings do I need?
The pickup, vent and return ports are all 3/8" NPT. Supply your own final fittings and plugs.

How do I vent the tank?
Through the 3/8" NPT vent port on top, plumbed to a vapor canister or filter, or with a vented or managed vent cap.

Does it have a drain?
No. This tank has no drain port.

Does it come with a level sensor?
No. The tank has no sender mount as standard. Add the 5-bolt SAE flange at checkout, alone, with a block-off kit or with a mechanical gauge.

Can I feed more than one engine from this tank?
Yes. Add up to 3 extra pickup tubes (4 total) at checkout.

What fuels can I use?
Gasoline or diesel. Choose a cap rated for your fuel.

Is the tank baffled?
No. It has no baffles.

What is the warranty?
A 2-year limited structural warranty. Thread damage from dry-fitted plugs or hardware isn't covered.

Can you modify this tank or build a custom one?
Yes, but not for a single tank. We can't make any changes for a one-tank order. Custom or modified tanks require a 5–10 piece order, and drawing fees usually apply. Contact us for more information.

Do you offer bulk pricing?
Yes. Bulk pricing and discounts are available on larger orders, starting as low as 10 pieces. Contact us for a quote.
