15 Gallon 24x14x12 Aluminum Tank

15 Gallon 24x14x12 Aluminum Tank

Availability : Ships in 1-2 weeks or Less

11021

$347.16
$347.16
Sale Sold out
Shipping calculated at checkout.

15-Gallon Universal Aluminum Fuel Tank, 24" x 14" x 12" (#11021)

A simple, unbaffled 15-gallon universal tank built from 1/8" 5052 aluminum, with a top-mount 5-bolt SAE sender flange, one installed pickup tube, a 1/2" NPT vent, and 3/8" NPT return and drain ports. You choose the fill cap or neck, level sensor, extra pickup tubes and rollover vent at checkout.

Technical Specifications

  • Product number: 11021
  • Capacity: 15 gallons
  • Body dimensions: 24" L x 14" W x 12" H
  • Footprint: 24" x 17" including mounting tabs
  • Height with cap: 13.975"
  • Material and thickness: 5052 aluminum, 0.125" (1/8"), mill finish
  • Baffles: None
  • Weld fittings: 6061-T6 aluminum, flush style
  • Fill: 2" NPSM or 225 Series neck, or 2.0" / 1.5" OD hose barb
  • Vent: 1/2" NPT
  • Sender provision: 5-bolt SAE flange
  • Pickup / draw: 3/8" NPT
  • Return: 3/8" NPT
  • Drain: 3/8" NPT port, low on the side wall
  • Mounting: Four 1.5" x 1.5" x 0.125" aluminum angle tabs, 2" long
  • Dry weight: 26 lb (approx.)
  • Pressure test: Fully pressure tested (5–8 psi) and inspected
  • Fuel: Gasoline or diesel. Choose a cap rated for your fuel.
  • Warranty: 2-year limited structural warranty
  • Custom / modified tanks: 5–10 piece order required (no single-tank changes)
  • Bulk pricing: available from 10 pieces

Tank Options & Provisions

Fill (Tank Cap / Neck Option)
On top, at the opposite end from the sender flange. There is no standard neck; the fill is set by the cap or neck you choose at checkout. Choose one rated for your fuel. All tanks must be vented to work properly. With a non-vented cap, vent the tank through the 1/2" NPT port or use a managed vent cap. Open vented caps will leak.

Vent (Rollover Vent Option)
1/2" NPT flush 6061-T6 aluminum port on top, next to the fill. Add the #32001 rollover vent at checkout, or leave the bung open for your own vent line. Plumb the vent to a vapor canister or filter.

Sending Unit (Level Sensor Option)
5-bolt SAE sender flange on top. A sensor or the block-off plate is required to use the tank; have us install one or install your own.

Pickup (Pickup Tube Options)
One pickup tube is installed: 3/8" NPT half coupling on top, 1/4" Sch 40 aluminum tube, 11.75" long with a 15° cut. One is all you need unless you're running multiple engines.

  • No Thanks- 1 pickup tube is all I need.
  • Install (1) Additional Pickup Tube (2 Pickups Total)
  • Install (2) Additional Pickup Tubes (3 Pickups Total)
  • Install (3) Additional Pickup Tubes (4 Pickups Total)

Return
3/8" NPT flush 6061-T6 aluminum port on top, beside the sender flange.

Drain
3/8" NPT flush 6061-T6 aluminum port, low on the side wall. Plug it if you don't use it. Aluminum threads cross-thread and gall easily. Start every plug and fitting by hand and never install them dry. Thread damage from dry-fitted plugs or hardware isn't covered under warranty.

Included

  • Tank with one pickup tube installed
  • Fill cap or neck, sender option, extra pickup tubes and rollover vent option as selected at checkout

Not Included

  • Final threaded fittings, plugs and mounting hardware for your install (we do not sell these)

Install Notes

  • The tank must be vented. Open vented caps will leak. With a non-vented cap, vent through the 1/2" NPT port or use a managed vent cap, and plumb the vent to a vapor canister or filter.
  • A sensor or the block-off kit must be installed on the sender flange before the tank is used.
  • Aluminum threads cross-thread and gall easily. Start every plug and fitting by hand and never install them dry. Thread damage from dry-fitted plugs or hardware isn't covered under warranty.
  • Measure your application before ordering. Full dimensions and port locations are on the reference drawing in the product photos.
  • Put rubber isolator pads (or similar rubber isolation) under the mounting tabs to isolate the tank from vibration and chafe.
  • See our Universal Fuel Tank Selection, Install & Fitment Guide to compare sizes, ports, venting, mounting and level sensors.

FAQ

What size fittings do I need?
The vent is 1/2" NPT. The pickup, return and drain ports are 3/8" NPT. Supply your own final fittings and plugs.

How do I vent the tank?
Plumb the 1/2" NPT vent port to a vapor canister or filter, with or without the optional rollover vent.

Can I add a rollover vent?
Yes. Add the #32001 1/2" NPT brass rollover vent at checkout, or leave the bung open for your own vent line.

Does it come with a level sensor?
The 5-bolt SAE sender flange is standard. Choose a 0-90 or 240-33 ohm sensor, a mechanical gauge or the block-off kit at checkout, or install your own.

Can I feed more than one engine from this tank?
Yes. Add up to 3 extra pickup tubes (4 total) at checkout.

What fuels can I use?
Gasoline or diesel. Choose a cap rated for your fuel.

Is the tank baffled?
No. It has no baffles.

What is the warranty?
A 2-year limited structural warranty. Thread damage from dry-fitted plugs or hardware isn't covered.

Can you modify this tank or build a custom one?
Yes, but not for a single tank. We can't make any changes for a one-tank order. Custom or modified tanks require a 5–10 piece order, and drawing fees usually apply. Contact us for more information.

Do you offer bulk pricing?
Yes. Bulk pricing and discounts are available on larger orders, starting as low as 10 pieces. Contact us for a quote.
